Marine & Industry, Navigation Led
L655779769
Navigation LED Bay15d T17x55mm 10-30V 100-300mA 380Lm 3W 6500K 865 AC/DC IP65 EMC approved Ship lamp
- > 2 year warranty
- Quality higher than average in the market
- IP65, for use outside
- Suitable for 12V until 30V
- Navigation led
- Marine and automotive application
- Good lumen/watt/quality ratio
Downloads
Datasheet Photos Energylabel Product Information SheetRequest quote
Specifications
| General | |
| Eprel registration no | 626839 |
| Socket | Bay15d |
| Bulb shape | T17 |
| Width | 17.00 mm |
| Depth | 17.00 mm |
| Height | 55.00 mm |
| Lamp shape | Tubular shape |
| Finish | Clear |
| Colour | Colourless Daylight |
| Body material | Polycarbonat |
| Lifespan | 25000 hours |
| Switches | 50000 |
| Beam angle | 360 ° |
| Dimmable | No |
| Degree of protection | IP65 |
| Net weight | 0.012 kg |
| Warranty | 2 years |
Light |
|
| Kelvin | 6500 K |
| Colour temp nr | 865 |
| Colour temperature | Daylight white |
| Stable lumen | 380 lm |
| Color Rendering Index (CRI) | 80 |
| Energy | ||
| Volt | 10..30 V | |
| Frequency | 50..60 Hz | |
| Watt | 3 W | |
| Current type | AC/DC | |
| Power factor | 0.6 | |
| Energy efficiency class | E | |
| Product excluded by regulation | No | |
| Energy consumption | 3 W | |
| Replacement wattage | 34 W | |
| Lamp efficacy | 126.67 | |
LED |
||
| Filament LED | No | |
| LED type | SMD | |
| Dimm type | Non-Dim | |
| Number of leds / sticks | 27 | |
| Colour consistency SDCM | SDCM5 | |
| Dim to warm | No | |
| Adjustable beam angle | No | |
Ordering details |
Quantity pc(s) |
EAN |
| Article number | L655779769 | |
| Single package | 1 | 8718739058880 |
| Inner carton | 10 | 18718739058887 |
| Outer carton | 100 | 28718739058884 |
