Marine & Industry, Tubular VR 10-30V Premium
L024372427-1
LED Ba15d Tube T17x47mm 10-30V 360° 190Lm 2W 2700K 827 360° AC/DC Clear Non-Dimmable
- > 2 year warranty
- Quality higher than average in the market
- Suitable for 12V until 30V
- Marine and automotive application
Downloads
Datasheet Photos Energylabel Product Information SheetRequest quote
Specifications
| General | |
| Eprel registration no | 831245 |
| Socket | Ba15d |
| Bulb shape | T17 |
| Width | 17.00 mm |
| Depth | 17.00 mm |
| Height | 47.00 mm |
| Lamp shape | Tube, single-ended |
| Finish | Clear |
| Colour | Colourless |
| Body material | Polycarbonat |
| Lifespan | 25000 hours |
| Switches | 50000 |
| Beam angle | 360 ° |
| Dimmable | No |
| Degree of protection | IP20 |
| Net weight | 0.014 kg |
| Warranty | 3 years |
Light |
|
| Kelvin | 2700 K |
| Colour temp nr | 827 |
| Colour temperature | Warm white |
| Stable lumen | 190 lm |
| Color Rendering Index (CRI) | 82 |
| Energy | ||
| Volt | 10..30 V | |
| Frequency | 50..60 Hz | |
| Watt | 2 W | |
| Current type | AC/DC | |
| Power factor | 0.5 | |
| Energy efficiency class | F | |
| Product excluded by regulation | No | |
| Energy consumption | 2 W | |
| Replacement wattage | 20 W | |
| Lamp efficacy | 95.00 | |
LED |
||
| Filament LED | No | |
| LED type | SMD | |
| Dimm type | Non-Dim | |
| Number of leds / sticks | 13 | |
| Colour consistency SDCM | SDCM5 | |
| Dim to warm | No | |
| Adjustable beam angle | No | |
Ordering details |
Quantity pc(s) |
EAN |
| Article number | L024372427-1 | |
| Single package | 1 | 8718739064355 |
| Inner carton | 10 | 18718739064352 |
| Outer carton | 100 | 28718739064359 |
